感应加热用 高压谐振塑壳系列
四铜针引出
六铜针引出
铜端子引出
★特点
□阻燃PBT塑壳封装、阻燃环氧灌封
□具有耐压高、过电流能力强、温升低、频率特性好
□等效串联电阻小、杂散电感低
★应用场合
□广泛应用于商用/工业感应加热，以及各类电力电子设备中作谐振电容使用
★技术要求
|
引用标准
|
GB/3984，IEC60110
|
|
气候类别
|
40/105/21
|
|
工作温度范围（外壳）
|
-40℃～105℃
|
|
电压范围
|
1600～4000V.DC
|
|
容量范围
|
0.01μF～2μF
|
|
容量允许偏差
|
±5%（J）/±10%（K）
|
|
损耗角正切值
|
10×10-4
|
|
耐电压
|
1.5Un（60S，20±5℃）
|
|
绝缘电阻
|
≥5000S(500VDC,60S)
|
|
过电压
|
1.1Un30%ofon-load-dur.·0
|
|
1.15Un30min/day
|
|
1.2Un5min/day
|
|
1.3Un1min/day
|
|
最高使用海拔
|
2000m
|
|
预期寿命
|
20000h（Un，θhs=70℃）
|
|
失效率
|
50FIT
|
备注：如果海拔使用高度超过2000m，应该考虑海拔对对流冷却和外绝缘的影响
★技术参数
|
3000VDC
|
|
Cn
(μF)
|
Dimension(mm)
|
Irms@70℃@100KHz（A）
|
dv/dt
(V/μs)
|
Ipeak
(A)
|
ESR@10KHz(mΩ)
|
Partnumber
|
|
L
|
B
|
H
|
P
|
P2
|
P3
|
P4
|
|
0.10
|
42
|
27
|
41
|
38
|
10
|
|
|
20
|
1000
|
100
|
31
|
1GRBH410D3000-01
|
|
0.10
|
42
|
27
|
41
|
|
|
|
34
|
20
|
1000
|
100
|
31
|
1GRBH410D3000-02
|
|
0.15
|
42
|
24
|
38
|
|
|
|
34
|
20
|
1000
|
150
|
21
|
1GRBH415D3000-02
|
|
0.15
|
42
|
24
|
38
|
38
|
10
|
|
|
20
|
1000
|
150
|
21
|
1GRBH415D3000--
|
|
0.15
|
42
|
33
|
45.5
|
|
|
10
|
|
30
|
1000
|
150
|
21
|
1GRBH415D3000-03
|
|
0.18
|
42
|
24
|
38
|
38
|
10
|
|
|
20
|
1000
|
180
|
17
|
1GRBH418D3000-01
|
|
0.18
|
42
|
24
|
38
|
|
|
|
34
|
20
|
1000
|
180
|
17
|
1GRBH418D3000-02
|
|
0.18
|
42
|
33
|
45.5
|
38
|
|
10
|
|
30
|
1000
|
180
|
17
|
1GRBH418D3000-03
|
|
0.20
|
42
|
27
|
41
|
|
|
|
34
|
20
|
1000
|
200
|
16
|
1GRBH420D3000-02
|
|
0.20
|
42
|
33
|
45.5
|
|
|
|
34
|
30
|
1000
|
200
|
17
|
1GRBH420D3000-01
|
|
0.20
|
42
|
36
|
52
|
38
|
|
10
|
|
35
|
1000
|
200
|
17
|
1GRBH420D3000-06
|
|
0.22
|
42
|
27
|
41
|
|
|
|
34
|
20
|
1000
|
220
|
15
|
1GRBH422D3000-01
|
|
0.22
|
42
|
27
|
41
|
38
|
10
|
|
|
20
|
1000
|
220
|
15
|
1GRBH422D3000-02
|
|
0.22
|
42
|
33
|
45.5
|
|
|
|
34
|
30
|
1000
|
220
|
15
|
1GRBH422D3000-08
|
|
0.24
|
42
|
33
|
45.5
|
38
|
|
10
|
|
30
|
1000
|
240
|
14
|
1GRBH424D3000-03
|
|
0.24
|
42
|
27
|
41
|
|
|
|
34
|
20
|
1000
|
240
|
14
|
1GRBH424D3000-06
|
|
0.27
|
42
|
33
|
45.5
|
|
|
|
34
|
30
|
1000
|
270
|
12
|
1GRBH427D3000-01
|
|
0.27
|
42
|
33
|
45.5
|
38
|
|
10
|
|
30
|
1000
|
270
|
12
|
1GRBH427D3000-03
|
|
0.30
|
42
|
33
|
45.5
|
|
|
|
34
|
30
|
1000
|
300
|
11
|
1GRBH430D3000-01
|
|
0.30
|
42
|
33
|
45.5
|
38
|
|
10
|
|
30
|
1000
|
300
|
11
|
1GRBH430D3000-02
|
|
0.30
|
42
|
36
|
52
|
|
|
|
34
|
35
|
1000
|
300
|
11
|
1GRBH430D3000-04
|
|
0.33
|
42
|
33
|
45.5
|
38
|
|
10
|
|
30
|
1000
|
330
|
10
|
1GRBH433D3000-01
|
|
0.33
|
42
|
33
|
45.5
|
|
|
|
34
|
30
|
1000
|
330
|
10
|
1GRBH433D3000-03
|
|
0.35
|
42
|
33
|
45.5
|
38
|
|
10
|
|
30
|
1000
|
350
|
9
|
1GRBH435D3000-04
|
|
0.35
|
42
|
33
|
45.5
|
|
|
|
34
|
30
|
1000
|
350
|
9
|
1GRBH435D3000-06
|
|
0.39
|
42
|
33
|
45.5
|
38
|
|
10
|
|
30
|
1000
|
390
|
8.5
|
1GRBH439D3000-05
|
|
0.40
|
42
|
36
|
52
|
|
|
|
34
|
35
|
1000
|
400
|
8
|
1GRBH440D3000-02
|
|
0.45
|
42
|
36
|
52
|
38
|
|
10
|
|
35
|
1000
|
450
|
7.5
|
1GRBH445D3000-01
|
|
0.45
|
42
|
36
|
52
|
|
|
|
34
|
35
|
1000
|
450
|
7.5
|
1GRBH445D3000-02
|
|
4000VDC
|
|
Cn
(μF)
|
Dimension(mm)
|
Irms@70℃@100KHz（A）
|
dv/dt
(V/μs)
|
Ipeak
(A)
|
ESR@10KHz(mΩ)
|
Partnumber
|
|
L
|
B
|
H
|
P
|
P2
|
P3
|
P4
|
|
0.10
|
42
|
27
|
41
|
38
|
10
|
|
|
20
|
1000
|
100
|
31
|
1GRBH410D4000-
|
|
0.10
|
42
|
27
|
41
|
|
|
|
34
|
20
|
1000
|
100
|
31
|
1GRBH410D4000-
|
|
0.15
|
42
|
24
|
38
|
|
|
|
34
|
20
|
1000
|
150
|
21
|
1GRBH415D4000-
|
|
0.15
|
42
|
24
|
38
|
38
|
10
|
|
|
20
|
1000
|
150
|
21
|
1GRBH415D4000-
|
|
0.15
|
42
|
33
|
45.5
|
|
|
10
|
|
30
|
1000
|
150
|
21
|
1GRBH415D4000-
|
|
0.18
|
42
|
24
|
38
|
38
|
10
|
|
|
20
|
1000
|
180
|
17
|
1GRBH418D4000-
|
|
0.18
|
42
|
24
|
38
|
|
|
|
34
|
20
|
1000
|
180
|
17
|
1GRBH418D4000-
|
|
0.18
|
42
|
33
|
45.5
|
38
|
|
10
|
|
30
|
1000
|
180
|
17
|
1GRBH418D4000-
|
|
0.20
|
42
|
27
|
41
|
|
|
|
34
|
20
|
1000
|
200
|
16
|
1GRBH420D4000-
|
|
0.20
|
42
|
33
|
45.5
|
|
|
|
34
|
30
|
1000
|
200
|
17
|
1GRBH420D4000-
|
|
0.20
|
42
|
36
|
52
|
38
|
|
10
|
|
35
|
1000
|
200
|
17
|
1GRBH420D4000-
|
|
0.22
|
42
|
27
|
41
|
|
|
|
34
|
20
|
1000
|
220
|
15
|
1GRBH422D4000-
|
|
0.22
|
42
|
27
|
41
|
38
|
10
|
|
|
20
|
1000
|
220
|
15
|
1GRBH422D4000-
|
|
0.22
|
42
|
33
|
45.5
|
|
|
|
34
|
30
|
1000
|
220
|
15
|
1GRBH422D4000-
|
|
0.24
|
42
|
33
|
45.5
|
38
|
|
10
|
|
30
|
1000
|
240
|
14
|
1GRBH424D4000-
|
|
0.24
|
42
|
27
|
41
|
|
|
|
34
|
20
|
1000
|
240
|
14
|
1GRBH424D4000-
|
|
0.27
|
42
|
33
|
45.5
|
|
|
|
34
|
30
|
1000
|
270
|
12
|
1GRBH427D4000-
|
|
0.27
|
42
|
33
|
45.5
|
38
|
|
10
|
|
30
|
1000
|
270
|
12
|
1GRBH427D4000-
|
|
0.30
|
42
|
33
|
45.5
|
|
|
|
34
|
30
|
1000
|
300
|
11
|
1GRBH430D4000-
|
|
0.30
|
42
|
33
|
45.5
|
38
|
|
10
|
|
30
|
1000
|
300
|
11
|
1GRBH430D4000-
|
|
0.30
|
42
|
36
|
52
|
|
|
|
34
|
35
|
1000
|
300
|
11
|
1GRBH430D4000-
|
|
0.33
|
42
|
33
|
45.5
|
38
|
|
10
|
|
30
|
1000
|
330
|
10
|
1GRBH433D4000-
|
|
0.33
|
42
|
33
|
45.5
|
|
|
|
34
|
30
|
1000
|
330
|
10
|
1GRBH433D4000-
|
|
0.35
|
42
|
33
|
45.5
|
38
|
|
10
|
|
30
|
1000
|
350
|
9
|
1GRBH435D4000-
|
|
0.35
|
42
|
33
|
45.5
|
|
|
|
34
|
30
|
1000
|
350
|
9
|
1GRBH435D4000-
|
|
0.39
|
42
|
33
|
45.5
|
38
|
|
10
|
|
30
|
1000
|
390
|
8.5
|
1GRBH439D4000-
|
|
0.40
|
42
|
36
|
52
|
|
|
|
34
|
35
|
1000
|
400
|
8
|
1GRBH440D4000-
|
|
0.45
|
42
|
36
|
52
|
38
|
|
10
|
|
35
|
1000
|
450
|
7.5
|
1GRBH445D4000-
|
|
0.45
|
42
|
36
|
52
|
|
|
|
34
|
35
|
1000
|
450
|
7.5
|
1GRBH445D4000-
|
